Description

What is ASUS PRIME H610M-K D4?

The ASUS PRIME H610M-K D4 is an entry-level Micro-ATX motherboard based on the Intel® H610 chipset. It supports 12th Gen Intel® Core™ processors on the LGA1700 socket and DDR4 memory, making it suitable for budget gaming PCs, office systems, and everyday desktop builds.

Key Specifications

Chipset: Intel® H610
Socket: LGA1700
Form Factor: Micro-ATX

Supported Processors

Supports:

• 12th Gen Intel® Core™ Processors
• Intel® Pentium® Gold Processors
• Intel® Celeron® Processors

CPU Power Support

• Supports CPUs up to 65W TDP

Memory Support

RAM Configuration

• 2 x DDR4 DIMM Slots
• Maximum Capacity: 64GB
• Dual Channel Architecture

Supported Memory Speeds

• DDR4-3200
• DDR4-3000
• DDR4-2933
• DDR4-2800
• DDR4-2666
• DDR4-2400
• DDR4-2133

Memory Features

• Non-ECC Unbuffered Memory
• Intel® XMP Support

Graphics Support

Graphics output depends on the installed CPU with integrated graphics.

Video Outputs

• 1 x HDMI Port
• 1 x D-Sub (VGA) Port

Expansion Slots

PCIe Slots

CPU

• 1 x PCIe 4.0 x16 Slot

Chipset

• 1 x PCIe 3.0 x1 Slot

Storage Support

M.2 Storage

• 1 x M.2 Slot
• Supports:
  • 2242
  • 2260
  • 2280 SSDs
• PCIe 3.0 x4 NVMe Support

SATA Storage

• 4 x SATA 6Gb/s Ports

Networking

LAN

• Realtek 1Gb Ethernet

USB Connectivity

Rear USB Ports

• 2 x USB 3.2 Gen 1 Type-A
• 4 x USB 2.0 Type-A

Front USB Headers

• 1 x USB 3.2 Gen 1 Header (adds 2 ports)
• 1 x USB 2.0 Header (adds 2 ports)

Audio Features

Audio Codec

• Realtek 7.1 High Definition Audio CODEC

Audio Features

• Jack Detection
• Multi-streaming
• Front Panel Jack Retasking
• Audio Shielding
• Premium Audio Capacitors
• Dedicated Audio PCB Layers
• Up to 24-Bit / 192kHz Playback

Rear I/O Ports

• 2 x USB 3.2 Gen 1 Type-A
• 4 x USB 2.0 Type-A
• 1 x HDMI Port
• 1 x D-Sub Port
• 1 x Realtek Gigabit LAN Port
• 3 x Audio Jacks
• 1 x PS/2 Keyboard Port
• 1 x PS/2 Mouse Port

BIOS

• UEFI BIOS

Operating System Support

• Windows 11 64-bit
• Windows 10 64-bit

Form Factor

• Micro-ATX

Warranty

• 3 Years

Best Use Cases

This motherboard is ideal for:

• Budget gaming PCs
• Office computers
• Home-use systems
• Entry-level productivity builds
• Basic Intel 12th Gen builds

Important Limitations

Before purchasing, note these limitations:

• Only supports CPUs up to 65W officially
• No CPU overclocking support
• Limited VRM capability for high-end CPUs
• Only 2 RAM slots
• No Wi-Fi included
• Basic H610 chipset features

Recommended CPU Pairings

Good CPU combinations for this motherboard:

• Intel Core i3-12100
• Intel Core i5-12400
• Intel Core i5-13400 (BIOS compatibility may vary)

Not recommended for:

• High-power unlocked K-series processors
• Heavy workstation workloads
• Extreme gaming/streaming setups

Note*

• Price, feature, and specifications are subject to change without notice.
