Key Specifications

The Intel® Core™ i9-14900K includes the following specifications:

Architecture: Raptor Lake Refresh
Manufacturing Process: Intel 7
Total Cores: 24
Performance Cores: 8
Efficient Cores: 16
Threads: 32
Performance-core Base Clock: 3.2 GHz
Performance-core Max Turbo Clock: Up to 5.6 GHz
Efficient-core Base Clock: 2.4 GHz
Efficient-core Max Turbo Clock: Up to 4.4 GHz
Intel® Thermal Velocity Boost: Up to 6.0 GHz
Intel® Turbo Boost Max Technology 3.0: Up to 5.8 GHz
Intel Smart Cache: 36 MB
L2 Cache: 32 MB
Processor Base Power: 125W
Maximum Turbo Power: 253W
Socket: FCLGA1700
Unlocked for Overclocking: Yes
Maximum Operating Temperature (TJunction): 100°C

Operating System Support

The Intel® Core™ i9-14900K supports modern 64-bit operating systems including:

• Windows 11 (64-bit)

• Windows 10 (64-bit)

• Linux distributions such as Ubuntu and other x86 64-bit systems

Operating system compatibility may vary depending on motherboard and chipset support.

Connectivity Features

PCI Express Support: PCIe® 5.0 and PCIe® 4.0
Maximum PCIe Lanes: 20
PCIe Configurations: Up to 1×16+4 or 2×8+4
DMI Revision: 4.0
Maximum DMI Lanes: 8
Memory Support: DDR5-5600 or DDR4-3200
Memory Channels: Dual Channel
Maximum Memory Capacity: 192 GB
Maximum Memory Bandwidth: 89.6 GB/s
ECC Memory Support: Yes

Graphics Capabilities

The Intel® Core™ i9-14900K includes integrated Intel® UHD Graphics 770, allowing display output without requiring a dedicated graphics card.

Graphics Base Frequency: 300 MHz
Graphics Max Dynamic Frequency: 1.65 GHz
Execution Units: 32
Maximum Displays Supported: 4
HDMI Maximum Resolution: 4096 × 2160 @ 60Hz
DisplayPort Maximum Resolution: 7680 × 4320 @ 60Hz
eDP Maximum Resolution: 5120 × 3200 @ 120Hz
DirectX Support: 12
OpenGL Support: 4.5
OpenCL Support: 3.0
Intel® Quick Sync Video: Yes

Advanced Technologies

• Intel® Thread Director

• Intel® Adaptive Boost Technology

• Intel® Thermal Velocity Boost

• Intel® Turbo Boost Max Technology 3.0

• Intel® Turbo Boost Technology 2.0

• Intel® Hyper-Threading Technology

• Intel® Gaussian & Neural Accelerator 3.0

• Intel® Deep Learning Boost (DL Boost)

• Intel® Speed Shift Technology

• Intel® Volume Management Device (VMD)

Security Features

• Intel® AES New Instructions

• Intel® Control-Flow Enforcement Technology

• Intel® Secure Key

• Intel® OS Guard

• Intel® Boot Guard

• Execute Disable Bit

• Intel® Virtualization Technology (VT-x)

• Intel® Virtualization Technology for Directed I/O (VT-d)

• Intel® VT-x with Extended Page Tables (EPT)

Warranty & Important Note

Warranty: 3 Years

*Prices, features, and specifications are subject to change without prior notice.
