Description

What is Intel® Core™ Ultra 5 225?

The Intel® Core™ Ultra 5 225 is a next-generation desktop processor from Intel’s Core™ Ultra Series 2 lineup, based on the advanced Arrow Lake architecture. Designed for modern gaming, productivity, AI acceleration, and content creation, it combines Performance-cores and Efficient-cores with built-in AI acceleration through Intel® AI Boost NPU, integrated Intel® Graphics, DDR5 memory support, and PCIe® 5.0 connectivity.

Key Specifications

The Intel® Core™ Ultra 5 225 includes the following specifications:

Architecture: Arrow Lake
Manufacturing Process: TSMC N3B
Total Cores: 10
Performance Cores: 6
Efficient Cores: 4
Low Power Efficient Cores: 0
Threads: 10
Performance-core Base Clock: 3.3 GHz
Performance-core Max Turbo Clock: Up to 4.9 GHz
Efficient-core Base Clock: 2.7 GHz
Efficient-core Max Turbo Clock: Up to 4.4 GHz
Intel Smart Cache: 20 MB
L2 Cache: 22 MB
Processor Base Power: 65W
Maximum Turbo Power: 121W
Overall AI Performance: Up to 23 TOPS (Int8)
Socket: FCLGA1851
Maximum Operating Temperature: 105°C

AI & NPU Features

The Intel® Core™ Ultra 5 225 includes a dedicated AI engine for accelerated AI workloads.

Intel® AI Boost NPU

NPU Peak Performance: 13 TOPS (Int8)
Sparsity Support: Yes
Windows Studio Effects Support: Yes

Supported AI Frameworks

• OpenVINO™
• WindowsML
• DirectML
• ONNX Runtime
• WebNN
• WebGPU

AI Acceleration Technologies

• Intel® Deep Learning Boost (DL Boost)
• Intel® Gaussian & Neural Accelerator 3.5

Operating System Support

The Intel® Core™ Ultra 5 225 supports modern 64-bit operating systems including:

• Windows 11 (64-bit)
• Windows 10 (64-bit)
• Linux distributions such as Ubuntu and other x86 64-bit systems

Operating system compatibility may vary depending on motherboard and chipset support.

Connectivity Features

PCI Express Support: PCIe® 5.0 and PCIe® 4.0
Maximum PCIe Lanes: 24
PCIe Configurations: Up to 1×16+2×4, 2×8+2×4, or 1×8+4×4
DMI Revision: 4
Maximum DMI Lanes: 8
Thunderbolt™ 4 Support: Yes
Memory Support: DDR5-6400
Memory Channels: Dual Channel
Maximum Memory Capacity: 256 GB

Graphics Capabilities

The Intel® Core™ Ultra 5 225 includes integrated Intel® Graphics for smooth display output, media acceleration, and AI-enhanced graphics workloads.

Graphics Base Frequency: 300 MHz
Graphics Max Dynamic Frequency: 1.8 GHz
Xe-Cores: 2
GPU Peak AI Performance: 4 TOPS (Int8)
Maximum Displays Supported: 4
HDMI Maximum Resolution: Up to 7680 × 4320 @ 60Hz
DisplayPort Maximum Resolution: 7680 × 4320 @ 60Hz
eDP Maximum Resolution: 3840 × 2400 @ 120Hz
DirectX Support: 12
OpenGL Support: 4.5
OpenCL Support: 3.0
Intel® Quick Sync Video: Yes
AV1 Encode/Decode: Yes

Advanced Technologies

• Intel® Thread Director
• Intel® Turbo Boost Technology 2.0
• Intel® Speed Shift Technology
• Intel® Deep Learning Boost (DL Boost)
• Intel® Gaussian & Neural Accelerator 3.5
• Intel® Volume Management Device (VMD)

Security Features

• Intel® Threat Detection Technology (TDT)
• Intel® Trusted Execution Technology
• Intel® AES New Instructions
• Intel® Secure Key
• Intel® OS Guard
• Intel® Boot Guard
• Execute Disable Bit
• Intel® Virtualization Technology (VT-x)
• Intel® Virtualization Technology for Directed I/O (VT-d)
• Intel® VT-x with Extended Page Tables (EPT)

Warranty & Important Note

Warranty: 3 Years

*Prices, features, and specifications are subject to change without prior notice.
