| # of Cores | 2 |
| # of Threads | 4 |
| Processor Base Frequency | 3.7 GHz |
| TDP | 51 W |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 64 GB |
| Memory Types | DDR4-1866/2133, DDR3L-1333/1600 @ 1.35V |
| Max # of Memory Channels | 2 |
| Max Memory Bandwidth | 34.1 GB/s |
| ECC Memory Supported ‡ | Yes |
| Graphics Specifications | |
| Processor Graphics ‡ | Intel® HD Graphics 530 |
| Graphics Base Frequency | 350 MHz |
| Graphics Max Dynamic Frequency | 1.05 GHz |
| Graphics Video Max Memory | 1.7 GB |
| Graphics Output | eDP/DP/HDMI/DVI |
| 4K Support | Yes, at 60Hz |
| Max Resolution (Intel® WiDi)‡ | 1080p |
| Max Resolution (HDMI 1.4)‡ | 4096×2304@24Hz |
| Max Resolution (DP)‡ | 4096×2304@60Hz |
| Max Resolution (eDP – Integrated Flat Panel)‡ | 4096×2304@60Hz |
| Max Resolution (VGA)‡ | N/A |
| DirectX* Support | 12 |
| OpenGL* Support | 4.4 |
| Intel® Quick Sync Video | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Insider™ | Yes |
| Intel® Wireless Display | Yes |
| Intel® Clear Video HD Technology | Yes |
| Intel® Clear Video Technology | Yes |
| # of Displays Supported ‡ | 3 |
| Device ID | 0x1912 |
| Expansion Options | |
| PCI Express Revision | 3 |
| PCI Express Configurations ‡ | Up to 1×16, 2×8, 1×8+2×4 |
| Max # of PCI Express Lanes | 16 |
| Package Specifications | |
| Max CPU Configuration | 1 |
| Package Size | 37.5mm x 37.5mm |
| Graphics and IMC Lithography | 14 nm |
| Sockets Supported | FCLGA1151 |
| Low Halogen Options Available | See MDDS |
| Advanced Technologies | |
| Intel® Turbo Boost Technology ‡ | No |
| Intel® vPro Technology ‡ | No |
| Intel® Hyper-Threading Technology ‡ | Yes |
| Intel® Virtualization Technology (VT-x) ‡ | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes |
| Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes |
| Intel® TSX-NI | No |
| Intel® 64 ‡ | Yes |
| Idle States | Yes |
| Enhanced Intel SpeedStep® Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Identity Protection Technology ‡ | Yes |
| Intel® Stable Image Platform Program (SIPP) | No |
| Intel® Small Business Advantage | Yes |
| Intel® Data Protection Technology | |
| Intel® AES New Instructions | Yes |
| Secure Key | Yes |
| Intel® Platform Protection Technology | |
| OS Guard | Yes |
| Trusted Execution Technology ‡ | No |
| Execute Disable Bit ‡ | Yes |
| Warranty | 1 Years |
| Note | ***Features, Price and Specifications are subject to change without notice. |
