Description
| Supported CPU | Intel i3/i5/i7/Celeron/Pentium 6th,7th,8th & 9th generation series processor in LGA 1151 | |
| Chipset | Intel H110 | |
| Memory Supported | 2 No.s DDR4 DIMM Memory Slots Memory up to 32GB Supports DDR4 2133/2400/2666 MHz memory | |
| BIOS | AMI BIOS | |
| I/O Interface | 1 x HDMI port, 1 x VGA Port, 2 x USB 2.0 Port, 2 x USB 3.0 Port, 1 x RJ45 Port, 1 x 3-in-1 Audio Jacks, 1 x Display Port , 1 x PS/2 for Keyboard & Mouse | |
| Onboard Interface | 1 x 24 Pin ATX Power Connector, 1 x 4 Pin ATX 12V Power Connector,1 x Front Panel Connector, 1x Front Audio Connector, 1 x Speaker Connector, 1 x USB 2.0 Connectors, 1 x 4 Pin USB 2.0 Connector, 1 x USB 3.0 Connector, 1 x CPU Fan Connector, 1x SYS Fan Connector, 3 x SATA 3.0 | |
| Integrated LAN | Supports RTL8106E 10/100Mbps Ethernet LAN | |
| Expansion Slot | 1 x PCI Express x16 Slot, 1 x PCI Express x1 Slot, 1 x M.2 Slot, 1 x M.2 for WIFI module | |
| Form Factor | Micro-ATX | |
| Country of Origin | People’s Republic of China | |
| ||
| ZEB-Z310M2 Motherboard | 1U | |
| SATA Cable | 1U | |
| I/O Backplate | 1U | |
| Driver Disc | 1U | |
| User Manual | 1U |
LEGAL METROLOGY PRODUCT INFORMATION
| Imported & Marketed by: | |
| Country of Origin: | |
| Generic Name: | Zebronics Motherboard |
| Package Contents: | ZEB-Z310M2 Motherboard – 1U, SATA Cable – 1U, I/O Backplate – 1U, Driver Disc – 1U, User Manual – 1U |
| Customer Complaints: | Telephone – 044-4000 0004 | Email – enquiry@zebronics.com |
| Note | ***Features, Price, and Specifications are subject to change without notice. Images are used for Representation Purpose Only. |
